QF-QFB-750

Woven Bag Automatic Bottom Sealing, Cutting and Sewing Machine

Max. Diameter of Unwinding Roll (mm)1200

Max. Cutting Width (mm)800

Cutting Length (mm)600-1300

Cutting Accuracy (mm)±1.5

Bottom Folding Width (mm)15-30

Production Capacity (pcs/min)30-45

Play Product Video

Woven Bag Automatic Bottom Edge-banding, Cutting and Sewing Machine

Product Introduction

Fully automated cutting, bottom sewing and sealing - processes laminated or non-laminated PP woven bags with 70-80% labor reduction versus manual operations.

Product Parameters

Model No.	QF-QFB-750
Max. Diameter of Unwinding Roll (mm)	1200
Max. Cutting Width (mm)	800
Cutting Length (mm)	600-1300
Cutting Accuracy (mm)	±1.5
Bottom Folding Width (mm)	15-30
Production Capacity (pcs/min)	30-45
Cutting Type	Hot cutting or cold cutting or both as required
Sewing Machine Type	Single Stitch (double stitch for options)
Stitch Pitch (mm)	7-12
Weight (kg)	4000 approx.
Installing Dimensions (LxWxH) (mm)	6000x8000x1700
Remarks	7.5kw air compressor prepared by the customer

Product Details

01.

Fully automated cutting, bottom sewing and edge-banding - processes laminated or non-laminated PP woven bags with 70-80% labor reduction versus manual operations.

02.

It enhances seam sealing by applying an adhesive tape (hot-melt or cold glue) over stitched seams, with optional heating for thermal-bonding tapes.

03.

Precision-length control: User-friendly touchscreen and servo motor system maintains ±1.5mm accuracy on every bag.

04.

Hot cutting seals edges without adhesion for a smooth bag opening, while cold cutting provides clean, fray-resistant edges with no heat distortion, ensuring consistent performance in both modes.
